6GK5761-1FC00-0AB0

Material ID: 6GK5761-1FC00-0AB0

• IWLAN Access Point, SCALANCE W761-1 RJ45
• 1 radio, 1 R-SMA antenna port
• IEEE 802.11a/b/g/h/n, 2.4/5 GHz
• Gross data rate 150 Mbps
• 1x RJ45 max. 100 Mbps
• 24 V DC, joint block, IP20
• 0… +55 °C
• WPA2/802.11i/e, observe national approvals!
• CERT ID: ELN-W1-RJ-E1, FCC ID: LYHELN1V1
• Scope of delivery: manuals on CD-ROM German/English, 1x joint block
• Only for operation in the USA
• SCALANCE W761-1 RJ45 (US)
• 1x wireless, 1x R-SMA antenna port
• IEEE 802.11a/b/g/h/n, 2.4/5 GHz
• Gross data rate 150 Mbps
• 1x RJ45 max. 100 Mbps
• 24 V DC, terminal block, IP20
• For operation in the US
• For space-saving installation in the control cabinet on standard DIN rail
• 1 unit
• Access Point with a built-in wireless interface for installation in control cabinets in industrial plants, such as suspended monorails and automatic guided vehicle systems
• The device enables wireless commissioning in the plant
• Implementation of simple and cost-effective wireless machine networking
• Predictable data traffic (deterministic response) and defined response times on the wireless link as well as reliable wireless connection
• Particularly future-proof through conformity with universally accepted WLAN standard IEEE 802.11
• Wireless access for service and maintenance, light and small design for efficient usage in automatic guided vehicle systems (AGV), expandable with video data
• Space-saving installation thanks to SIMATIC design
• The comprehensive accessories include a wide antenna portfolio, plug-in connectors, stripping tools, mounting accessories as well as cabling technology that top off the system
